Identify NVMe disks in an HPE vSAN environment

Replacing a failed disk or identifying an internal disk to be replaced is always a delicate task, because we don’t want to introduce additional failures. Especially in vSAN enabled clusters with different failure to tolerate settings. Of course, a vSAN enabled server can be placed into maintenance mode with full data migration and VMware has done a great job in creating visibility of the used components in a vSAN environment, including the identify disk led.

Enter Maintenance mode
vSphere ESXi Enter Maintenance mode

But sometimes things just don’t add up and you need additional confirmation to be absolutely sure that the correct disk is replaced. Therefore I was looking for a way to match the information displayed on the ILO page of an HPE DL380 Gen10 with the information displayed in vCenter for a vSAN NVMe disk.

On the ILO page the model and serial number are shown for a given NVMe disk.

NVMe disk as seen in HPE ILO or ONEview

In vCenter the model number for an NVMe disk can be easily retrieved. But unless you have completely different disks in the servers, the model number isn’t very useful.

NVMe disk as seen in vCenter UI
NVMe disk as seen in vCenter UI

The NVMe disk as presented in vCenter shows as t10.NVME__<model number>_______<GUID>. This GUID can’t be found in the ILO. So how can we retrieve the serial number for a specific NVMe disk?

From the ESXi CLI several commands can be used to retrieve information about a disk drive. Since this is a vSAN host I started with the standard vSAN command: esxcli vsan storage list

With this command the model number can be easily found, but the serial number isn’t listed.

vSAN NVMe disk as from the ESXCLI
vSAN NVMe disk as from the ESXCLI

After some Google work and a discussion with an HPE employee we found that we needed the command: esxcli nvme device list instead.

With this command the NVMe disks and their related vmHBA numbers are shown. When the vmHBA adapter is added to the previous command, we get the serial number of the disk: esxcli nvme devicve get -A vmhba1

NVMe disk as from the ESXCLI
NVMe disk as from the ESXCLI

The last step is to relate the vmHBAx number to the correct disk.

This can be done with the command: esxcfg-scsidevs -A


Now we can be completely confident that when we’re replacing the disk, we will get the correct one. This is also extremely useful when instructing a colleague on-site, or when using the remote hands in a datacenter.

Hopefully these steps provide you with some additional guidance and insurance when replacing or identifying NVMe disks.
